2022 Evil Insurgent v2

The Insurgent is Evil's hardest-partying trail bike

The new 2022 Evil Insurgent v2 is a lot of things. It's a powerful enduro rig, capable downhill racer, aggressive trail shredder, and a park rat and freerider wrapped up in a couple savagely awesome models. It's a take-no-prisoners mountain bike that specializes in all things steep, fast, and fun. Read on to check out what new insanity Evil has cooked up.

Explore the 2022 Evil Insurgent v2

  • Wheel size: Mixed 29/27.5 (MX) or full 27.5
  • Front travel: 170mm (MX) / 180mm (27.5)
  • Rear travel: 168mm
  • Size range: S - XL
Trail rider on the 2022 Evil Insurgent v2

Who it's for

The new Evil Insurgent is for riders who want untouchable confidence on steeps and in the air while retaining a lively ride quality that's super fun and agile.

There are two expertly crafted models to haunt the dreams of both enduro-minded riders and jump-lovers alike, and as long as you like to go hard, the Evil Insurgent could be perfect for you.

rider getting air on the Evil Insurgent

Why you'll love it

You'll love the Insurgent v2 because you'll be able to ride even harder and more confidently on the gnarliest lines out there.

It's still crazy nimble for next level maneuverability, but with more travel and a geometry that's been tweaked for better downhill control, you'll feel like there's no trail you can't own and no jump you'll want to miss.

What's new on the 2022 Insurgent v2?

The 2022 Evil Insurgent v2 has undergone some major tweaks in order to create an even more fun and capable ride. Check out a few of the big highlights below.

The 2022 Evil Insurgent v2 comes in a mixed wheel set up or 27.5

MX (29/27.5) or full 27.5"

Choose your weapon.

If you want maximum maneuverability or your spend your days in the park hitting big jump lines, the 27.5 model is the move.

If you're more inclined to ride big declines, the mixed wheel model will give you the enduro capabilities of a 29er without giving up the same berm slashing agility.

More rear travel

The rear travel has been increased from 150mm up to 168mm for even more bottomless suspension and bigger sends.

Better pedaling efficiency

The seat tube has been steepened quite a bit (76.9° for MX and 78° for 27.5") in order to make climbs easier so you can efficiently earn your turns.

More downhill stability

The longer reach and wheelbase will help keep you more centered and confident on those chunky steeps where maximum control is an absolute necessity.


2022 Evil Insurgent v2 Geometry

Since the 2022 Evil Insurgent v2 comes in either mixed wheels or full 27.5", there are some differences in the geometry that make each option specially suited for a certain kind of rowdy.

Insurgent v2 MX 29SMLXL
Head Tube Angle
(Low/X-Low)
64.2° / 63.5°64.2° / 63.5°64.2° / 63.5°64.2° / 63.5°
Seat Tube Angle
(Low/X-Low)
76.9° / 76.2°76.9° / 76.2°76.9° / 76.2°76.9° / 76.2°
Virtual Top Tube Length
(Low/X-Low)
595mm / 598mm612mm / 615mm633mm / 636mm654mm / 657mm
Seat Tube Length390mm425mm460mm490mm
Bottom Bracket Height
(Low/X-Low)
358mm / 349mm358mm / 349mm358mm / 349mm358mm / 349mm
Bottom Bracket Drop
(Low/X-Low)
1mm / 8mm1mm / 8mm1mm / 8mm1mm / 8mm
Head Tube Length104mm114mm127mm139mm
Chain Stay Length
(Low/X-Low)
430mm / 432mm430mm / 432mm430mm / 432mm430mm / 432mm
Wheel Base
(Low/X-Low)
1215mm / 1217mm1236mm / 1238mm1262mm / 1264mm1287mm / 1289mm
Axle To Crown586mm586mm586mm586mm
Fork Offset44mm44mm44mm44mm
Front To Center785mm785mm785mm785mm
Trail (Low/X-Low)131mm / 136mm131mm / 136mm131mm / 136mm131mm / 136mm
Stack (Low/X-Low)612mm / 617mm621mm / 626mm632mm / 637mm643mm / 648mm
Reach (Low/X-Low)443mm / 447mm460mm / 453mm480mm / 473mm500mm / 593mm
Stand Over (Low/X-Low)705mm / 699mm716mm / 709mm724mm / 718mm736mm / 730mm
Insurgent v2 27.5SMLXL
Head Tube Angle
(Low/X-Low)
65.3° / 64.7°65.3° / 64.7°65.3° / 64.7°65.3° / 64.7°
Seat Tube Angle
(Low/X-Low)
78.2° / 77.5°78.2° / 77.5°78.2° / 77.5°78.2° / 77.5°
Virtual Top Tube Length
(Low/X-Low)
590mm / 593mm607mm / 610mm628mm / 631mm650mm / 653mm
Seat Tube Length390mm425mm460mm490mm
Bottom Bracket Height
(Low/X-Low)
349mm / 341mm349mm / 340mm349mm / 340mm349mm / 340mm
Bottom Bracket Drop
(Low/X-Low)
8mm / 16mm8mm / 16mm8mm / 16mm8mm / 16mm
Head Tube Length104mm114mm127mm139mm
Chain Stay Length
(Low/X-Low)
430mm / 432mm430mm / 432mm430mm / 432mm430mm / 432mm
Wheel Base
(Low/X-Low)
1211mm / 1213mm1233mm / 1235mm1258mm / 1260mm1283mm / 1285mm
Axle To Crown577mm577mm577mm577mm
Fork Offset44mm44mm44mm44mm
Front To Center781mm781mm781mm781mm
Trail (Low/X-Low)116mm / 120mm116mm / 120mm116mm / 120mm116mm / 120mm
Stack (Low/X-Low)612mm / 617mm621mm / 626mm632mm / 637mm643mm / 648mm
Reach (Low/X-Low)456mm / 449mm473mm / 466mm492mm / 486mm512mm / 506mm
Stand Over (Low/X-Low)692mm / 686mm703mm / 696mm711mm / 704mm724mm / 718mm

2022 Evil Insurgent v2 Models

Shop the 2022 Evil Insurgent v2 GX

Insurgent v2 GX

  • Frame: UD Carbon
  • Shock:  RockShox Super Deluxe Coil Ultimate
  • Fork: RockShox ZEB Ultimate
  • Drivetrain: SRAM GX Eagle, 12sp
  • Price: $5,999
Shop the 2022 Evil Insurgent v2 X01

Insurgent v2 X01

  • Frame: UD Carbon
  • Shock:  RockShox Super Deluxe Coil Ultimate
  • Fork: RockShox ZEB Ultimate
  • Drivetrain: SRAM X01 Eagle, 12sp
  • Price: $7,599
Shop the 2022 Evil Insurgent v2 X01 AXS

Insurgent v2 X01 AXS

  • Frame: UD Carbon
  • Shock:  RockShox Super Deluxe Coil Ultimate
  • Fork: RockShox ZEB Ultimate
  • Drivetrain: SRAM X01 Eagle AXS, 12sp
  • Price: $8,299
